1550nm Single frequency Low Power Fiber Laser System

Desk Type

Module Type

The 1550nm single frequency laser (low power) adopts DFB semiconductor laser chip, single mode fiber output, professionally designed drive circuit and TEC control to ensure the safe and stable operation of the laser, can provide desktop or modular package.

Characteristics

Apply
High output power Nonlinear optical
Stable spectrum Fiber sensing
  Fiber Laser

Model   SL-FL-1550nm-xxx mW
Specifications Unit   Remarks
Wavelength nm
1550\0.5
1540~1565nm optional
Spectral line width
MHz 3 1MHz optional
Side band inhibition ratio dB >50
Output  Power mW 10/20/50/100/200 optional
Short-term stability (15 min) dB
<\0.02

Long-term stability (8 hours) dB <\0.05
Operating temperature -5 - +55
Operating humidity % 0-70
Fiber mode SMF-28e SM or PM1550
Fiber connector FC/APC
Operating voltage DC5V or 100-240VAC
Control mode Button or RS232
Communication interface DB9 Female optional
Work mode
ACC/APC

Size

260(W)〜280(D)〜120(H)

125(W)〜150(D)〜20(H)

Desk Type

Module Type

Warranty time One year
Order information/model
Model Output  Power(mW) Out Fiber Package
SL-FL-1550nm- 10/20/50/100/200
SM= SMF-28e
PM=PM1550
D=desk type

M=module
