Single
Longitudinal Mode 1342nm
1-500mW DPSS Laser |
|
 |
 |
|
Specifications
|
|
Model
|
SL-1342nm-SLM-XXXmW
|
|
Output
Power @ 25 ≧
|
1-500mW
|
|
Wavelength
|
1342＼1nm
|
|
Transverse mode |
TEM00 |
|
Longitudinal mode |
Single |
|
Spectral linewidth (nm) |
<0.00001 |
|
Operation
Mode |
CW |
|
Power stability (rms, over 4
hours)
|
<5%
|
|
Warm-up time (minutes)
|
<10
|
|
M2 factor
|
<1.2
|
|
Beam Divergence (1/e2, Full Angle)
|
< 1.5mrad
|
|
Beam diameter at the aperture
(mm)
|
<2.0
|
|
Polarization ratio |
>100:1(Horizontalor or
Vertical Optional) |
|
Pointing stability after
warm-up (mrad) |
<0.05 |
|
Noise of amplitude (rms,
1~20MHz) |
<1% |
|
Coherent length (m) |
>50 |
|
Operating temperature
|
10≧゛35≧ |
|
Input Voltage |
80-265VAC |
|
Modulation
|
No |
|
Expected Operating Lifetime
|
>10000 hours
|
|
Warranty time |
One year |
|
|
|
