DPSS 543nm
1-100mW Low Noise Laser
|
|
|
|
|
Specifications
|
|
Model
|
SL-543nm-XXXT
|
|
Output
Power @ 25 ≧
|
1-100mW
|
|
Wavelength
|
543nm＼1nm
|
|
Transverse mode |
TEM00 |
|
Operation
Mode |
CW |
|
Power stability (rms, over 4
hours)
|
<5%
|
|
Warm-up time (minutes)
|
<15
|
|
M2 factor
|
<1.5
|
|
Beam Divergence (1/e2, Full Angle)
|
< 1.5mrad
|
|
Beam diameter at the aperture
(mm)
|
<2.0
|
|
Polarization ratio
|
>100:1
|
|
Operating temperature
|
10≧゛30≧
|
|
Input Voltage
|
|
|
Modulation
|
TTL Modulation or Analog
Modulation
|
|
Expected Operating Lifetime
|
>10000 hours
|
|
Warranty time |
One year
|
