488nm
1-50mw Cross Line Output Compact Blue
Laser Module
|
|
|
Specifications
|
Model
|
SL-488nm-LM-CL-xx
mW
|
Output
Power @ 25 ≧
|
1-50mW
|
Wavelength
|
488nm\5nm
|
Operation
Mode
|
CW,TEM00
|
Power stability
(rms, over 4 hours)
|
<5%(over 2 hours)
|
Warm-up time
(minutes)
|
<1
|
M2 factor
|
<5
|
Beam
Divergence (1/e2, Full Angle)
|
< 5.0mrad
|
Beam diameter
at the aperture (mm)
|
<5
|
Fan Angle |
45-135< |
Lens |
Plastic, Glass or Powell Lens |
Beam Width |
+2mm @ 1m |
Operating temperature
|
15≧゛30≧
|
Dimensions
|
Dia.12〜50mm
(Can be designed to other
size according to customer's requirement)
|
Input Voltage
|
3-5VDC |
Expected Operating Lifetime
|
>5000 hours
|
Warranty time |
One year
|
|
|
