520nm 1000-2000mw Laser System

Specifications

Model

SL-520nm-xxxxT

Output Power @ 25 ≧

1000-1000mW

(1000,1500 and 2000mW optional)

Wavelength

520nm

Operation Mode

CW
Transverse mode Multimode
Power stability (rms, over 4 hours) <5%
Warm-up time (minutes)
<5
Beam Divergence (1/e2, Full Angle)
< 1.2 x 0.3mrad
Beam diameter at the aperture (mm)
<4.0
Cooling
TEC
Operating temperature
10≧゛35≧
Modulation
TTL,0-30kHz
Dimensions of Laser Head
150 x 65 x 70mm
Input Voltage
85-265VAC
Expected Operating Lifetime
>10000 hours
Warranty Time
1 year
　 　
　 　
