532nm 5mW Green Laser Module (Cross Line)

Specifications
Model	SL-532nm-GLM-012(Cross Line)
Wavelength	532nm(green)
Output power	1 - 5mW(10mW,20mW,30mW,50mW optional)
Operation Mode	CW,TEM₀₀ Fixed Focus, Cross Line Light Shape
Working Current	<280mA
Operating Voltage	DC=2.7V～3.2V
Beam of Light Emanative Angle	2.4mrad
Expected operating lifetime	> 5000 hours
Laser Size(mm)	Φ14x65mm(This size can be set according to customers needs)
Line Width	φ1.0mm at minimum
