532nm 5mW Green Laser Module (Horizontal Line)

Specifications
Model SL-532nm-GLM-011(Horizontal Line)
Wavelength 532nm(green)
Output power

1 - 5mW

(10mW, 20mW, 30mW, 50mW optional)

Operation Mode
CW,TEM00

Fixed Focus, Straight Line (Horizontal Line)

Working Current <280mA
Operating Voltage DC=2.7V～3.2V
Beam of Light Emanative Angle 2.4mrad
Expected operating lifetime > 5000 hours
Laser Size(mm)

Φ14x65mm(This size can be set according to customers needs)
Line Width  φ1.0mm at minimum
