1550nm
2-10W Laser System |
|
 |
 |
|
Specifications
|
|
Model
|
SL-1550nm-xxW
|
|
Output
Power @ 25 ¡æ
|
2-10W
|
|
Wavelength
|
1550¡À10nm
|
|
Transverse mode |
TE00 |
|
Operation
Mode |
CW |
|
Power stability (rms, over 4
hours)
|
<5%
|
|
Warm-up time (minutes)
|
<10
|
|
M2 factor
|
<2.0
|
|
Beam Divergence (1/e2, Full Angle)
|
< 3.0mrad
|
|
Beam diameter at the aperture
(mm)
|
<5.0
|
|
Polarization state |
Random / >15dB |
|
Pointing stability after
warm-up (mrad) |
<0.05 |
|
Operating temperature |
10¡æ¡«35¡æ |
|
Input Voltage
|
80-265VAC or 12VDC |
|
Modulation
|
TTL Modulation or Analog
Modulation |
|
Expected Operating Lifetime
|
>10000 hours
|
|
Warranty time |
One year |
|
¡¡ |
¡¡ |
