785nm 1-350mW Diode Laser



Specifications

Model

SL-785nm-XXXT

Output Power @ 25 ≧

1-350mW(5mW,10mW,20mW,50mW,100mW,200mW,300mW  and 350mW optional )

Wavelength

785nm＼10nm

Operation Mode

CW
Transverse Mode Near TEM00
Power stability (rms, over 4 hours) <3%
Warm-up time (minutes)
<5
M2 factor
<1.5
Beam Divergence (1/e2, Full Angle)
< 2.0mrad
Beam diameter at the aperture (mm)
 <4.0
Polarization ratio
>50:1

Pointing stability after warm-up (mrad)
<0.05
Operating temperature (≧)
10゛35
Input Voltage (VAC)
85-265
Modulation
TTL or Analog Modulation
Expected Operating Lifetime
>10000 hours
Warranty time
one year



　
