850nm 1-15000mW Laser



Specifications

Model

SL-850nm-XXXT

Output Power @ 25 ¡æ

100-1500mW(100mW,200mW,500mW,1000mW and 1500mW optional)

Wavelength

850nm¡À10nm

Operation Mode

CW
Transverse Mode Multimode
Power stability (rms, over 4 hours) <3%
Warm-up time (minutes)
<5
M2 factor
<10
Beam Divergence (1/e2, Full Angle)
< 3.0mrad
Beam diameter at the aperture (mm)
 ¡«5 x 8
Operating temperature (¡æ)
10¡«35
Input Voltage (VAC)
85-265
Modulation
TTL or Analog Modulation
Expected Operating Lifetime
>10000 hours
Warranty time
one year
