DPSS 671nm 2-5W Red Laser
|
|
|
|
|
Specifications
|
|
Model
|
SL-671nm-XXXXT
|
|
Output
Power @ 25 ¡æ
|
2-5W
|
|
Wavelength
|
671nm
|
|
Operation
Mode
|
CW, Near TEM00
|
|
Power stability
(rms, over 4 hours)
|
<5%
|
|
Warm-up time
(minutes)
|
<15
|
|
M2 factor
|
<2
|
|
Beam
Divergence (1/e2, Full Angle)
|
< 2mrad
|
|
Beam diameter
at the aperture (mm)
|
<3
|
|
Spectral
linewidth (nm)
|
<0.1
|
|
Polarization
ratio
|
>100:1
|
|
Operating
temperature
|
15¡æ¡«30¡æ
|
|
Dimensions of
Laser head (mm)
|
333
¡Á 140 ¡Á 125mm
|
|
Input Voltage
|
80-260VAC
|
|
Modulation
|
TTL Modulation or Analog Modulation
|
|
Dimensions of
power supply
|
324 x 277 x142mm
|
|
Expected
Operating Lifetime
|
>10000 hours
|
|
Warranty time
|
One year
|
|
 |
 |
