Scanner
Performance Parameters:
Voltage:AC220-240V/50-60HZ
Power:60W
Net Weight:4KG
Size:420*250*80mm
Fuse:F2A 5*20mm
Signal Input Voltage 10V
Max Scan 200
Rotor Intertia 0.015gm cm2
Torque Constant 2.4X104dyne cm/amp Coil Inductance 120uh
Coil resistance 3.5¦¸
Max Coil Temperature 1000C
Cross Swing Peanlum 50uradp Pmax
Radial
Wiggling Pendulum 80uradp Pmax
Max peak Current Of Driring 6amps
Max average Current 1.5amps
Small Angle Step Resonse 0.4ms, with balanced inertia matched
load
Linearity:98%,minimum,over 30 degrees
Repeatability:50urad max
Non linearity: 80p-p
Plus excursion 0.05%1C max
Null off set 0.01%1C max
